505066-5022 Original stock-wholesale price

The image is for reference only



505066-5022

Manufacturer Model： 505066-5022
Manufacturer： Molex
Package/Specification

Product Description： Board to Board & Mezzanine Connectors SlimStack .35mm Rcpt Armor Nail 50Ckt

Place of delivery：China （Including VAT） Lead time(weekday）：2 hour shipping

Stock：

Spot goods3590（1 Starting order） (China：2 hour shipping)

Quantity：x（unit-price）Not the latest price, please consult customer service for details「Package(TR) / 1」

Consult Now

Advantage spot

4-11404-2

T3477-018

SBM51214G

I-2X12FOM3LM-CAS-MA

I-2X12FOM3LM-CAS-MB

I-2X12FOM3LM-CAS-FA

Product Details
Technical Documentation

Product Classification	Board to Board & Mezzanine Connectors
Manufacturer:	Molex
Product Category:	Board to Board & Mezzanine Connectors
RoHS:	Details
Product:	Receptacles
Number of Positions:	50 Position
Pitch:	0.35 mm
Number of Rows:	2 Row
Termination Style:	Solder
Mounting Angle:	Vertical
Stack Height:	0.6 mm
Current Rating:	300 mA
Voltage Rating:	50 V
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 85 C
Contact Plating:	Gold
Contact Material:	Copper
Housing Material:	Liquid Crystal Polymer (LCP)
Series:	505066
Packaging:	Reel
Packaging:	Cut Tape
Application:	Board to Board
Brand:	Molex
Flammability Rating:	UL 94 V-0
Mounting Style:	PCB
Product Type:	Board to Board & Mezzanine Connectors

Technical Documentation
Data Book	505066-5022.pdf
