UCC23513BQDWYQ1 Original stock-wholesale price

The image is for reference only



UCC23513BQDWYQ1

Manufacturer Model： UCC23513BQDWYQ1
Manufacturer： Texas Instruments
Package/Specification

Product Description： IC ISOLATION

Place of delivery：China （Including VAT） Lead time(weekday）：2 hour shipping

Stock：

Spot goods3590（1 Starting order） (China：2 hour shipping)

Quantity：x2.03553（unit-price）Not the latest price, please consult customer service for details「Package(TR) / 1」

Consult Now

Advantage spot

4-11404-2

T3477-018

SBM51214G

I-2X12FOM3LM-CAS-MA

I-2X12FOM3LM-CAS-MB

I-2X12FOM3LM-CAS-FA

Product Details
Technical Documentation

Product Classification	Isolators - Gate Drivers
Mfr	Texas Instruments
Series	Automotive, AEC-Q100, Functional Safety (FuSa)
Package	Tape & Reel (TR)
Product Status	Active
Technology	Capacitive Coupling
Number of Channels	1
Voltage - Isolation	5700Vrms
Common Mode Transient Immunity (Min)	150kV/µs
Propagation Delay tpLH / tpHL (Max)	105ns, 105ns
Pulse Width Distortion (Max)	35ns
Current - Output High, Low	28ns, 25ns (Max)
Current - Output High, Low	3A, 3.5A

Technical Documentation
Data Book	UCC23513BQDWYQ1.pdf
