ACPL-W343-560E Original stock-wholesale price

The image is for reference only



ACPL-W343-560E

Manufacturer Model： ACPL-W343-560E
Manufacturer： Broadcom Limited
Package/Specification

Product Description： OPTOISO 5KV 1CH GATE DRIVER 6SO

Place of delivery：China （Including VAT） Lead time(weekday）：2 hour shipping

Stock：

Spot goods3590（1 Starting order） (China：2 hour shipping)

Quantity：x1.67479（unit-price）Not the latest price, please consult customer service for details「Package(TR) / 1」

Consult Now

Advantage spot

4-11404-2

T3477-018

SBM51214G

I-2X12FOM3LM-CAS-MA

I-2X12FOM3LM-CAS-MB

I-2X12FOM3LM-CAS-FA

Product Details
Technical Documentation

Product Classification	Isolators - Gate Drivers
Mfr	Broadcom Limited
Series	-
Package	Tape & Reel (TR)
Product Status	Active
Technology	Optical Coupling
Number of Channels	1
Voltage - Isolation	5000Vrms
Common Mode Transient Immunity (Min)	35kV/µs
Propagation Delay tpLH / tpHL (Max)	200ns, 200ns
Pulse Width Distortion (Max)	70ns
Current - Output High, Low	43ns, 40ns
Current - Output High, Low	3A, 3A

Technical Documentation
Data Book	ACPL-W343-560E.pdf
