HCPL0701R1 Original stock-wholesale price

The image is for reference only



onsemi HCPL0701R1

Manufacturer Model： HCPL0701R1
Manufacturer： onsemi
Package/Specification

Product Description： OPTOCOUPLER SGL DARL OUT 8-SOIC

Place of delivery：China （Including VAT） Lead time(weekday）：2 hour shipping

Stock：

Spot goods3590（1 Starting order） (China：2 hour shipping)

Quantity：x（unit-price）Not the latest price, please consult customer service for details「Package(TR) / 1」

Consult Now

Advantage spot

4-11404-2

T3477-018

SBM51214G

I-2X12FOM3LM-CAS-MA

I-2X12FOM3LM-CAS-MB

I-2X12FOM3LM-CAS-FA

Product Details
Technical Documentation

Product Classification	Optoisolators - Transistor, Photovoltaic Output
Mfr	onsemi
Series	-
Package	Tape & Reel (TR)
Product Status	Obsolete
Number of Channels	1
Voltage - Isolation	2500Vrms
Current Transfer Ratio (Min)	500% @ 1.6mA
Current Transfer Ratio (Max)	2600% @ 1.6mA
Turn On / Turn Off Time (Typ)	300ns, 1.6µs
Rise / Fall Time (Typ)	-
Output Type	DC
Output Type	Darlington with Base

Technical Documentation
Data Book	HCPL0701R1.pdf
